Massey Ferguson 7722
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | Massey Ferguson (a part of AGCO) |
| Type: | Row-Crop tractor |
| Factory: | Beauvais, France |
| Original price: | $167,691 (2015 Dyna-6 Classic ) |
| Original price: | $213,120 (2015 Dyna-VT Premium ) |
Massey Ferguson 7722 Power | |
| Engine (gross): | 200 hp 149.1 kW |
| PTO (claimed): | 165 hp 123.0 kW |
| Drawbar (tested): | 146.3 hp 109.1 kW |
| PTO (tested): | 205.2 hp 153.0 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Differential lock: | full-locking electro-hydraulic |
| Steering: | power |
| Brakes: | wet disc |
| Cab: | Cab standard with air-conditioning. AGCOMMAND ready |
| Transmissions: | 24-speed six-speed power shift |
| continuously-variable transmission (CVT) | |
Capacity | |
| Fuel: | 114 gal 431.5 L |
| Exhaust fluid (DEF): | 14 gal 53.0 L |
| Hydraulic system: | 26.4 gal 99.9 L |
Hydraulics | |
| Type: | closed center load sensing |
| Capacity: | 26.4 gal 99.9 L |
| Pressure: | 2900 psi 200.0 bar |
| Valves: | 3 to 5 |
| Pump flow: | 29 gpm 109.8 lpm |
| 39 gpm 147.6 lpm *Optional with Dyna-6 transmission. | |
| 50 gpm 189.3 lpm *Optional with Dyna-VT transmission | |
| SCV flow: | 24.3 gpm 92.0 lpm |
Tractor hitch | |
| Rear Type: | III |
| Control: | electronic lower-link draft sensing |
| Rear lift (at ends): | 13500 lbs 6123 kg *With Dyna-6 transmission |
| 15500 lbs 7030 kg *With Dyna-VT transmission | |
| Front Hitch: | IIIN |
| Front lift (at ends): | 7954 lbs 3607 kg |
| Drawbar: | Cat. 2 |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/1000 |
| 540/540E/1000 | |
| 540E/1000E/1000 | |
| 540/540E/1000/1000E | |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 175 |
| 240*Dual 120A alternators on Deluxe and Premium models. | |
| Batteries: | 2 |
| Battery CCA: | 600 |
| Battery volts: | 12 |
Engine Detail | |
| AGCO POWER AP74-4 | |
| turbocharged diesel | |
| 6-cylinder | |
| liquid-cooled | |
| Displacement: | 449.4 ci 7.4 L |
| Bore/Stroke: | 4.252x5.276 inches 108 x 134 mm |
| Emissions: | Tier 4 |
| Emission control: | selective catalytic reduction (SCR) |
| Power (gross): | 200 hp 149.1 kW |
| Maximum Power: | 215 hp 160.3 kW |
| Fuel system: | common rail |
| Cooling system: | electronic viscous fan |
| Air cleaner: | dual dry element |
| Rated RPM: | 2100 |
| Starter: | electric |
| Starter volts: | 12 |
Dimensions | |
| Weight: | 16535 lbs 7500 kg |
| Rear axle: | Bar: 3.74 by 112 inches 94 by 2844 mm |
