Massey Ferguson 6140

Production: 1995 - 1999

Production
Manufacturer:	Massey Ferguson (a part of AGCO)
Type:	Utility tractor

Massey Ferguson 6140 Power
Engine:	90 hp 67.1 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Differential lock:	electro-hydraulic front and rear
Steering:	power
Brakes:	wet disc
Cab:	Cab standard.
Transmissions:	16-speed two-speed power shift
32-speed four-speed power shift

Hydraulics
Type:	open center
Pressure:	2600 psi 179.3 bar
Pump flow:	13.2 gpm 50.0 lpm
Steering flow:	7.6 gpm 28.8 lpm
Steering press.:	247 psi 17.0 bar

Tractor hitch
Rear Type:	II
Rear lift (at 24"/610mm):	7562 lbs 3430 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/1000 (1.375)
Engine RPM:	540@1980 1000@2000
Front PTO:	independent
Front RPM:	1000
Engine RPM:	1000@2040

Electrical
Ground:	negative
Batteries:	2
Battery volts:	12

Engine Detail
Perkins 1004-4T2
turbocharged diesel
4-cylinder
liquid-cooled
Displacement:	244.1 ci 4.0 L
Bore/Stroke:	3.937x5.00 inches 100 x 127 mm
Power:	90 hp 67.1 kW
Rated RPM:	2200
Idle RPM:	850-2310
Torque:	265 lb-ft 359.3 Nm
Torque RPM:	1400
Starter:	electric
Starter volts:	12
Intake valve clearance:	0.008 inches 0.203 mm *Cold
Exhaust valve clearance:	0.018 inches 0.457 mm *Cold

Dimensions
2WD Wheelbase:	93.4 inches 237 cm
4WD Wheelbase:	93.5 inches 237 cm
2WD Length:	157.3 inches 399 cm
4WD Length:	160.2 inches 406 cm
Width:	101.2 inches 257 cm
Height (steering wheel):	77.6 inches 197 cm
Height (cab):	103.4 inches 262 cm
2WD Weight:	8690 lbs 3941 kg
4WD Weight:	9150 lbs 4150 kg
Clearance (drawbar):	15.2 inches 38 cm
