Massey Ferguson 5455

Production: 2005 - 2013

Production
Manufacturer:	Massey Ferguson
Type:	Utility tractor
Factory:	Beauvais, France

Massey Ferguson 5455 Power
Engine:	95 hp 70.8 kW
Drawbar (claimed):	67 hp 50.0 kW
PTO (claimed):	80 hp 59.7 kW
Drawbar (tested):	66.8 hp 49.8 kW
PTO (tested):	82.6 hp 61.6 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	hydrostaic power
Brakes:	independent hydraulic wet disc
Cab:	ROPS, cab optional
Transmission:	16-speed

Hydraulics
Type:	open center
closed optional
Pressure:	2900 psi 200.0 bar
Valves:	2 to 4
Total flow:	15 gpm 56.8 lpm (open)
34.8 gpm 131.7 lpm (combined flow)
29 gpm 109.8 lpm (closed)

Tractor hitch
Rear Type:	II
Rear lift (at 24"/610mm):	7,000 lbs 3175 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/1000
540E/1000 (optional)

Electrical
Ground:	negative
Charging amps:	80
Battery CCA:	505
Battery volts:	12

Engine Detail
Perkins 1104
wastegate turbocharged diesel
4-cylinder
liquid-cooled vertical
Displacement:	268.5 ci 4.4 L
Bore/Stroke:	4.134x5.00 inches 105 x 127 mm
Emissions:	Tier II
Power:	95 hp 70.8 kW
Air cleaner:	dual paper elements
Compression:	17.5:1
Rated RPM:	2200
Starter volts:	12

Transmission
Transmission:	Speedshift, mechnical powershift
Gears:	16 forward and reverse

Dimensions
Wheelbase:	97 inches 246 cm
Length:	165.7 inches 420 cm
Width:	79.3 inches 201 cm
Height:	108.3 inches 275 cm
Operating weight:	8,675 lbs 3934 kg (2WD)
9,305 lbs 4220 kg (4WD)
