Massey Ferguson 5440

Production: 2011 - 2013

Production
Manufacturer:	Massey Ferguson (a part of AGCO)

Massey Ferguson 5440 Power
Engine:	98.7 hp 73.6 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Differential lock:	standard
Steering:	power
Brakes:	hydraulic wet disc
Cab:	Cab standard with heater.
Transmission:	16-speed four-speed power shift

Hydraulics
Pressure:	2900 psi 200.0 bar
Valves:	2 to 4
Pump flow:	15.3 gpm 57.9 lpm
26.4 gpm 99.9 lpm *Optional Twin Flow system
Total flow:	23.8 gpm 90.1 lpm
Steering flow:	8.5 gpm 32.2 lpm

Tractor hitch
Rear Type:	II
Control:	position and draft control
Rear lift (at ends):	9480 lbs 4300 kg
Front lift:	5512 lbs 2500 kg

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	electro-hydraulic
Rear RPM:	540/540E (1.375)
540/1000*Optional
Engine RPM:	540@1980 540E@1550 1000@2000
Front PTO:	independent
Front RPM:	1000 (1.375)

Electrical
Ground:	negative
Charging system:	alternator
Battery volts:	12

Engine Detail
Perkins 1104D-44TA
turbocharged intercooled diesel
4-cylinder
liquid-cooled
Displacement:	268.5 ci 4.4 L
Bore/Stroke:	4.13x5.00 inches 105 x 127 mm
Power:	98.7 hp 73.6 kW
Maximum Power:	100.7 hp 75.1 kW
Torque:	296.5 lb-ft 402.1 Nm
Torque RPM:	1400
Starter:	electric
Starter volts:	12

Transmission
Transmission:	Dyna-4
Type:	four-speed power shift
Gears:	16 forward and reverse

Dimensions
Wheelbase:	96.9 inches 246 cm
Length:	166.2 inches 422 cm
Weight:	8378 lbs 3800 kg
