Massey Ferguson 5290

Production: 2002 - 2009

Production
Manufacturer:	Massey Ferguson (a part of AGCO)
Type:	Utility tractor
Factory:	Canoas, Brazil

Massey Ferguson 5290 Power
Engine:	88 hp 65.6 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Final drives:	planetary
Differential lock:	mechanical rear
Steering:	power
Brakes:	wet disc
Cab:	Two-post ROPS.
Transmissions:	12-speed
18-speed

Capacity
Fuel:	26.4 gal 99.9 L
Hydraulic system:	11.8 gal 44.7 L

Hydraulics
Type:	open center
Capacity:	11.8 gal 44.7 L
Pressure:	2176 psi 150.0 bar
Valves:	1 or 2
Total flow:	11.1 gpm 42.0 lpm

Tractor hitch
Rear Type:	II
Control:	position and depth control
Rear lift:	5512 lbs 2500 kg
7055 lbs 3200 kg *Optional

Power Take-off (PTO)
Rear PTO:	transmission
independent*Optional
Clutch:	254mm dry disc
Rear RPM:	540 (1.375)
540/1000 (1.375)
Engine RPM:	540@1900

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	35
Battery volts:	12
Battery AH:	90

Engine Detail
Perkins 4.41
diesel
4-cylinder
liquid-cooled
Displacement:	250.2 ci 4.1 L
Bore/Stroke:	3.98x5.00 inches 101 x 127 mm
Power:	88 hp 65.6 kW
Air cleaner:	dual element dry
Rated RPM:	2200
Torque:	214.6 lb-ft 291.0 Nm
Torque RPM:	1200
Starter:	electric
Starter volts:	12
Oil capacity:	10 qts 9.5 L

Dimensions
2WD Wheelbase:	89.1 inches 226 cm
4WD Wheelbase:	89.3 inches 226 cm
Length:	157.1 inches 399 cm
Height:	104 inches 264 cm
2WD Weight:	10362 lbs 4700 kg
4WD Weight:	11244 lbs 5100 kg
2WD Ground clearance:	16.4 inches 41 cm
4WD Ground clearance:	15.4 inches 39 cm
2WD Front tread:	54.7 to 48.4 inches 138 to 122 cm
4WD Front tread:	68.1 to 80.3 inches 172 to 203 cm
Rear tread:	60 to 91.9 inches 152 to 233 cm
