Massey Ferguson 4355

Production: 2001 - 2003

Production
Manufacturer:	Massey Ferguson
Type:	Utility tractor

Massey Ferguson 4355 Power
PTO (claimed):	85 hp 63.4 kW
Drawbar (tested):	65.6 hp 48.9 kW
PTO (tested):	84.1 hp 62.7 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	power
Brakes:	independent hydraulic wet disc
Cab:	Two-post foldable ROPS. Cab optional with air-conditioning.
Transmissions:	12-speed gear
12-speed power shuttle
24-speed power shuttle

Hydraulics
Type:	open center
Pressure:	3046 psi 210.0 bar
Valves:	2 to 4
SCV flow:	10 gpm 37.9 lpm
17.2 gpm 65.1 lpm *Combined flow
17.4 gpm 65.9 lpm *Optional dedicated flow with power shuttle

Tractor hitch
Rear Type:	II
Control:	position and draft control
Rear lift (at 24"/610mm):	3665 lbs 1662 kg
4495 lbs 2038 kg *Optional
Rear Arms:	telescopic lower links

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	hydraulic wet disc
Rear RPM:	540/1000
Engine RPM:	540@1902 1000@2000

Electrical
Ground:	negative
Charging system:	alternator
ROPS Charging amps:	45
Cab Charging amps:	80
Cab Charging amps:	120*Optional
Batteries:	2
Battery CCA:	590
Battery volts:	12

Engine Detail
Perkins
turbocharged diesel
4-cylinder
liquid-cooled
Displacement:	243.5 ci 4.0 L
Bore/Stroke:	3.937x5.00 inches 100 x 127 mm
Air cleaner:	dual paper elements
Compression:	17.3:1
Rated RPM:	2200
Starter volts:	12
Coolant capacity:	18.4 qts 17.4 L

Dimensions
Wheelbase:	93 inches 236 cm
Length:	163 inches 414 cm
Width:	81 inches 205 cm
Ground clearance:	14 inches 35 cm
2WD Front tread:	57 to 77 inches 144 to 195 cm
4WD Front tread:	55 to 75 inches 139 to 190 cm
Rear tread:	56 to 84 inches 142 to 213 cm
