Massey Ferguson 360

Production: 1987 - 1991

Production
Manufacturer:	Massey Ferguson
Type:	Utility tractor
Factory:	Coventry, England
Original price:	$18,000 (1988 2WD )
Original price:	$25,000 (1988 4WD )

Massey Ferguson 360 Power
PTO (claimed):	45 hp 33.6 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	hydrostatic power
Brakes:	wet disc
Cab:	Two-post ROPS. Canopy optional.
Transmissions:	8-speed gear
6-speed mechanical shuttle
12-speed synchromesh

Hydraulics
Pressure:	3000 psi 206.8 bar
Pump flow:	4.5 gpm 17.0 lpm (linkage pump)
9.2 gpm 34.8 lpm (aux pump)
Total flow:	13.7 gpm 51.9 lpm

Tractor hitch
Rear Type:	II/I
Control:	position and draft control
Rear lift:	3811 lbs 1728 kg

Power Take-off (PTO)
Rear PTO:	live
independent (optional)
Rear RPM:	540 (1.375)

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Perkins AT3.152.4
turbocharged diesel
3-cylinder
liquid-cooled
Displacement:	152 ci 2.5 L
Bore/Stroke:	3.60x5.00 inches 91 x 127 mm
Fuel system:	direct injection
Rated RPM:	2200
Starter:	electric
Starter volts:	12

Dimensions
Length:	131.6 inches 334 cm (2WD)
141.1 inches 358 cm (4WD)
2WD Height:	94.3 inches 239 cm
4WD Height:	93.8 inches 238 cm
Weight:	4910 lbs 2227 kg (2WD)
5346 lbs 2424 kg (4WD)
