Massey Ferguson 3070

Production: 1986 - 1992

Production
Manufacturer:	Massey Ferguson
Original price:	$41,800 (1992)

Massey Ferguson 3070 Power
PTO (claimed):	80 hp 59.7 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD (optional)
Steering:	hydrostatic power
Brakes:	hydraulic wet disc
Cab:	Cab standard with air-conditioning.
Transmissions:	32-speed
48-speed

Capacity
Fuel:	50 gal 189.3 L
Hydraulic system:	15.9 gal 60.2 L

Hydraulics
Type:	open
Capacity:	15.9 gal 60.2 L
Pressure:	2610 psi 180.0 bar
Valves:	2 to 4
Pump flow:	13.2 gpm 50.0 lpm

Tractor hitch
Rear Type:	II
Rear lift (at 24"/610mm):	6,900 lbs 3129 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/1000

Electrical
Charging system:	alternator
Charging amps:	55
Batteries:	2
Battery CCA:	420
Battery volts:	12

Engine Detail
Perkins AT4.236
turbocharged diesel
4-cylinder
liquid-cooled
Displacement:	236 ci 3.9 L
Rated RPM:	2200
Torque:	253 lb-ft 343.1 Nm
Torque RPM:	1400
Starter volts:	12

Dimensions
Wheelbase:	96.9 inches 246 cm
Length:	161 inches 408 cm (2WD)
165 inches 419 cm (4WD)
Height (cab):	109 inches 276 cm
Weight:	9,652 lbs 4378 kg (2WD)
10,192 lbs 4623 kg (4WD)
