Massey Ferguson 1165

Production: 1999 - 2002

Production
Manufacturer:	Massey Ferguson
Type:	Compact Utility tractor
Original price:	$25,400

Massey Ferguson 1165 Power
Engine (gross):	44 hp 32.8 kW
Engine (net):	42 hp 31.3 kW
PTO (claimed):	37 hp 27.6 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	hydrostatic power
Brakes:	mechanical wet disc
Cab:	ROPS
Transmissions:	16-speed synchronized
hydrostatic

Hydraulics
Pump flow:	7.4 gpm 28.0 lpm

Tractor hitch
Rear Type:	I
Rear lift:	3083 lbs 1398 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540
Mid PTO:	optional
Mid RPM:	2000

1165 Serial Numbers
1999:	H01001
2000:	J01001
2001:	K01001
2002:	L01001

Electrical
Ground:	negative
Charging amps:	45
Battery CCA:	622
Battery volts:	12

Engine Detail
Iseki E4CD
diesel
4-cylinder
liquid-cooled
Displacement:	134.1 ci 2.2 L
Bore/Stroke:	3.43x3.64 inches 87 x 92 mm
Power (gross):	44 hp 32.8 kW
Compression:	21.8:1
Rated RPM:	2500
Torque:	102.5 lb-ft 139.0 Nm
Torque RPM:	1500
Firing order:	1-3-4-2
Starter volts:	12
Oil capacity:	8.5 qts 8.0 L
Coolant capacity:	11.1 qts 10.5 L
Intake valve clearance:	0.014 inches 0.356 mm *Cold
Exhaust valve clearance:	0.014 inches 0.356 mm *Cold

Dimensions
Shiping weight:	4,280 lbs 1941 kg
