LS XU5055

Production: 2013 - 2016

Production
Manufacturer:	LS
Type:	Utility tractor

LS XU5055 Power
Engine (gross):	55 hp 41.0 kW
PTO (claimed):	46.5 hp 34.7 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	hydrostatic power
Brakes:	wet disc
Cab:	Two-post foldable ROPS. Cab optional with air-conditioning.
Transmission:	16-speed synchro shuttle

Hydraulics
Pump flow:	10.5 gpm 39.7 lpm
Total flow:	15.8 gpm 59.8 lpm
Steering flow:	5.3 gpm 20.1 lpm

Tractor hitch
Rear Type:	II
Control:	position and draft control
Rear lift:	4079 lbs 1850 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540 (1.375)

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	55
Battery volts:	12

Engine Detail
Shibarua N4LDI-TA
turbocharged diesel
4-cylinder
liquid-cooled
Displacement:	135.2 ci 2.2 L
Bore/Stroke:	3.307x3.937 inches 84 x 100 mm
Emissions:	Tier 4
Emission control:	exhaust-gas recirculation (EGR)
Power (gross):	55 hp 41.0 kW
Fuel system:	common rail direct injection
Rated RPM:	2600
Starter:	electric
Starter volts:	12

Transmission
Type:	synchro shuttle
Gears:	16 forward and reverse

Dimensions
Wheelbase:	80.3 inches 203 cm
Length:	141.5 inches 359 cm
Width:	67 inches 170 cm
Height (ROPS):	102.9 inches 261 cm
Height (cab):	100.7 inches 255 cm
Weight:	4674 lbs 2120 kg (2WD)
5121 lbs 2322 kg (Cab)
