LS R3039H

Production: 2011

Production
Manufacturer:	LS
Type:	Compact Utility tractor

LS R3039H Power
Engine (gross):	38.5 hp 28.7 kW
PTO (claimed):	29 hp 21.6 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	hydrostatic power
Brakes:	wet disc
Cab:	Two-post foldable ROPS.
Transmission:	hydrostatic

Hydraulics
Pump flow:	8.6 gpm 32.6 lpm
Total flow:	12.9 gpm 48.8 lpm
Steering flow:	4.3 gpm 16.3 lpm

Tractor hitch
Rear Type:	I
Control:	position and draft control
Rear lift:	1808 lbs 820 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540 (1.375)
Mid PTO:	independent (optional)
Mid RPM:	2000

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	50
Battery volts:	12

Engine Detail
Mitsibishi S4L2
diesel
4-cylinder
liquid-cooled
Displacement:	107.3 ci 1.8 L
Bore/Stroke:	3.071x3.622 inches 78 x 92 mm
Power (gross):	38.5 hp 28.7 kW
Rated RPM:	2700
Starter:	electric
Starter volts:	12

Transmission
Type:	hydrostatic
Gears:	infinite (3-range) forward and reverse

Dimensions
Wheelbase:	65.4 inches 166 cm
Length:	117.6 inches 298 cm
Width:	54.3 inches 137 cm
Height (ROPS):	92.6 inches 235 cm
Weight:	2780 lbs 1261 kg
