Leyland 802

Production: 1981 - 1982

Production
Manufacturer:	Leyland
Type:	Utility tractor
Original price:	$20,500 (1984)

Variants

2WD

Leyland 802 Power
Engine:	82 hp 61.1 kW
PTO (claimed):	74 hp 55.2 kW

Mechanical
Chassis:	4x2 2WD
Final drives:	spur gear
Differential lock:	mechanical rear
Steering:	power
Brakes:	hydraulic wet disc
Cab:	Cab standard with heat.
Transmission:	9-speed synchromesh

Hydraulics
Pressure:	2600 psi 179.3 bar
Pump flow:	14.5 gpm 54.9 lpm

Tractor hitch
Rear Type:	II
Control:	position and draft control
Rear lift:	5200 lbs 2358 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540

Electrical
Charging system:	alternator
Charging amps:	36
Battery volts:	12

Engine Detail
Leyland 4/98 TT
turbocharged diesel
4-cylinder
liquid-cooled
Displacement:	230 ci 3.8 L
Bore/Stroke:	3.86x4.92 inches 98 x 125 mm
Power:	82 hp 61.1 kW
Compression:	16.8:1
Rated RPM:	2200
Starter volts:	12

Transmission
Type:	synchromesh
Gears:	9 forward and 3 reverse
Clutch:	305mm hydraulic dry disc

Dimensions
Weight:	6550 lbs 2971 kg
