Ford GT-85
Type: Garden Tractors
Contents:
Production | |
| Distributor: | Ford |
| Manufacturer: | Shibaura |
| Type: | Garden tractor |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | manual |
| Steering: | power*Optional |
| Brakes: | disc |
| Cab: | Open operator station. |
| Transmission: | hydrostatic |
Capacity | |
| Fuel: | 4.2 gal 15.9 L |
Tractor hitch | |
| Rear Type: | 0*Optional |
Power Take-off (PTO) | |
| Rear PTO: | optional |
| Mid PTO: | independent |
| Clutch: | manual idler pulley |
| Front PTO: | independent |
| Clutch: | manual idler pulley |
GT-85 Serial Numbers | |
| Location: | Serial number plate on the left side of the tractor frame, above the front axle. |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
Engine Detail | |
| Kohler M18 | |
| gasoline | |
| 2-cylinder | |
| air-cooled horizontal-shaft | |
| Displacement: | 691 cc 42.18 ci |
| Bore/Stroke: | 3.12x2.75 inches 79 x 70 mm |
| Power (gross): | 18 hp 13.4 kW |
| Air cleaner: | dry |
| Starter volts: | 12 |
| Oil capacity: | 2.9 qts 2.7 L |
Transmission | |
| Type: | shaft-driven hydrostatic |
| Gears: | infinite (2-range) forward and reverse |
| Oil capacity: | 9.1 qts 8.6 L |
| 10.1 qts 9.6 L *Capacity with power steering. | |
Dimensions | |
| Wheelbase: | 49.8 inches 126 cm |
| Length: | 74.5 inches 189 cm |
| Width: | 39 inches 99 cm |
| Height (steering wheel): | 45 inches 114 cm |
| Shipping: | 1050 lbs 476 kg |
| Ground clearance: | 6.2 inches 15 cm |
