Bolens 1886

Production: 1971 - 1972

Production
Manufacturer:	Bolens
Type:	Garden tractor

Mechanical
Steering:	manual
power optional
Brakes:	disc
Cab:	Open operator station.
Transmission:	hydrostatic

Tractor hitch
Rear Type:	0*Optional

Power Take-off (PTO)
Mid PTO:	independent

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	30

Engine Detail
Kohler K482S
gasoline
2-cylinder
air-cooled horizontal-shaft horizontally-opposed
Displacement:	786 cc 48 ci
Bore/Stroke:	3.25x2.875 inches 83 x 73 mm
Power (gross):	18 hp 13.4 kW
Rated RPM:	3600
Starter:	electric
Starter volts:	12
Sparkplug:	Champion HR10
Sparkplug gap:	0.025 inches 0.635 mm
Point gap:	0.020 inches 0.508 mm

Transmission
Transmission:	Eaton 12
Type:	shaft-driven hydrostatic
Gears:	infinite forward and reverse
Oil capacity:	10 qts 9.5 L

Dimensions
Wheelbase:	52 inches 132 cm
Length:	76 inches 193 cm
Width:	38 inches 96 cm
Height:	45 inches 114 cm
Ground clearance:	8.5 inches 21 cm
