Wheel Horse L-105 Lawn Ranger
Type: Lawn Tractors
Contents:
Production | |
| Manufacturer: | Wheel Horse |
| Type: | Lawn tractor |
| Factory: | South Bend, Indiana, USA |
Variants | |
| recoil start | |
| electric start |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | manual |
| Cab: | Open operator station. |
| Transmission: | 3-speed |
L-105 Serial Numbers | |
| Location: | Serial number plate on the left side of the dashboard support on the L-105 Lawn Ranger, under the hood. |
Engine Detail | |
| Lauson | |
| gasoline | |
| 1-cylinder | |
| air-cooled | |
| Displacement: | 221 cc 13.53 ci |
| Bore/Stroke: | 2.625x2.50 inches 67 x 64 mm |
| Power: | 6 hp 4.5 kW |
| Starter type: | manual recoil |
Transmission | |
| Transmission: | Uni-Drive |
| Gears: | 3 forward and 1 reverse |
Dimensions | |
| Length: | 55 inches 139 cm |
| Height (steering wheel): | 34 inches 86 cm |
| Height (hood): | 29 inches 73 cm |
