Wheel Horse GT-14

Production: 1969 - 1973
Type: Garden Tractors

Contents:

Production

ManufacturerWheel Horse
TypeGarden tractor
FactorySouth Bend, Indiana, USA

Mechanical

Chassis4x2 2WD
Steeringmanual
CabOpen operator station.

Tractor hitch

Rear Type0 (optional)

GT-14 Serial Numbers

1969-unknown-
1970-unknown-
1971-unknown-
1972-unknown-
1973-unknown-

GT-14 Serial Location

Serial tag on the right side of Wheel Horse GT-14 dash support. Model codes listed below.

Electrical

Groundnegative
Battery volts12

Engine Detail

Kohler K321S
gasoline
1-cylinder
air-cooled
Displacement512 cc 31.27 ci
Bore/Stroke3.5x3.25 inches 89 x 83 mm
Power (gross)14 hp 10.4 kW
Rated RPM3600
Starter volts12

Transmission

ManufacturerSundstrand
Typehydrostatic
Gearsinfinite forward and reverse

Dimensions

Length70.5 inches 179 cm
Width37.5 inches 95 cm
Height41 inches 104 cm
Weight875 lbs*Early models are listed at 845 pounds. 396 kg
