Wheel Horse 14HP
Type: Garden Tractors
Contents:
14HP Serial Location | |
| Serial number plate on the left side of the Wheel Horse 14, below the dash support. |
Electrical | |
| Ground | negative |
| Charging amps | 15 |
| Battery volts | 12 |
| Battery AH | 42 |
Engine Detail | |
| Kohler K321S | |
| nautral gasoline | |
| 1-cylinder | |
| air-cooled | |
| Displacement | 512 cc 31.27 ci |
| Bore/Stroke | 3.50x3.25 inches 89 x 83 mm |
| Power | 14 hp 10.4 kW |
| Rated RPM | 3600 |
| Starter volts | 12 |
| Oil capacity | 2 qts 1.9 L |
Dimensions | |
| Wheelbase | 45.5 inches 115 cm |
| Length | 65 inches 165 cm |
| Width | 37 inches 93 cm |
| Height (steering wheel) | 39 inches 99 cm |
| Height (hood) | 35 inches 88 cm |
| Shiping weight | 680 lbs 308 kg |
| Ground clearance | 7.25 inches 18 cm |
