Simplicity Broadmoor 6HP 990303
Type: Lawn Tractors
Contents:
Production | |
| Manufacturer | Simplicity |
| Type | Lawn tractor |
| Factory | Port Washington, Wisconsin, USA |
Variants | |
| 990303 | large tire electric start |
| 990288 | large tire recoil start |
| 990287 | small tire recoil start |
Mechanical | |
| Chassis | 4x2 2WD |
| Steering | manual |
| Cab | Open operator station. |
Power Take-off (PTO) | |
| Front PTO | independent |
| Clutch | mechanical |
Electrical | |
| Ground | negative |
| Battery volts | 12 |
Engine Detail | |
| Briggs & Stratton 146702 | |
| gasoline | |
| 1-cylinder | |
| air-cooled vertical-shaft | |
| Displacement | 231 cc 14.11 ci |
| Bore/Stroke | 2.75x2.375 inches 70 x 60 mm |
| Power (gross) | 6 hp 4.5 kW |
| Starter | manual recoil |
| electric OptOptional | |
| Starter volts | 12 |
Transmission | |
| Type | belt-driven gear |
| Gears | 2 forward and 1 reverse |
Dimensions | |
| Wheelbase | 41.5 inches 105 cm |
| Length | 57 inches 144 cm |
| Width | 29.25 inches 74 cm |
| Height (steering wheel) | 33.5 inches 85 cm |
| Height (hood) | 31.5 inches 80 cm |
