Massey Ferguson 8
Type: Garden Tractors
Contents:
Production | |
| Distributor: | Massey Ferguson |
| Manufacturer: | AMF |
| Type: | Garden tractor |
| Factory: | Des Moines, Iowa, USA |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | manual |
| Brakes: | disc |
| Cab: | Open operator station. |
| Transmissions: | 3-speed gear |
| hydrostatic | |
8 Serial Numbers | |
| Location: | Serial number plate on the right side of the Massey Ferguson 8, below the dash panel. |
| 1972: | 500001 (Hydrostatic) |
| 1973: | 501717 (Hydrostatic) |
| 1974: | 100001 (Gear recoil) |
| 1974: | 300001 (Gear electric) |
| 1974: | 503932 (Hydrostatic) |
| 1975: | 101826 (Gear recoil) |
| 1975: | 306916 (Gear electric) |
| 1975: | 507934 (Hydrostatic) |
Electrical | |
| Ground: | negative |
| Battery volts: | 12 |
Engine Detail | |
| Tecumseh H80 | |
| gasoline | |
| 1-cylinder | |
| air-cooled | |
| Displacement: | 305 cc 18.65 ci |
| Bore/Stroke: | 3x2.75 inches 76 x 70 mm |
| Power: | 8 hp 6.0 kW |
| Rated RPM: | 3600 |
| Starter: | manual recoil |
| electric optional | |
| Starter volts: | 12 |
Dimensions | |
| Wheelbase: | 41 inches 104 cm |
| Length: | 58.5 inches 148 cm |
| Width: | 32.5 inches 82 cm |
| Height: | 36.5 inches 92 cm |
| Weight: | 505 lbs 229 kg *Weight with hydrostatic and mower deck. |
