John Deere 314

Production: 1979 - 1983

Production
Manufacturer	John Deere
Type	Garden tractor
Factory	Horicon, Wisconsin, USA

Mechanical
Chassis	4x2 2WD
Steering	manual
Brakes	shoe
Cab	Open operator station

Tractor hitch
Type	sleeve hitch OptOptional

Power Take-off (PTO)
Front PTO	independent
Clutch	electric

314 Serial Numbers
1979	C314H095001
1980	C314J120001
1981	C314K155001
1982	C314L190001
1983	M00314X222001
Final	M00314X285000

314 Serial Location

Serial number plate below steering column.

Electrical
Ground	negative
Battery volts	12

Engine Detail
Kohler K321AQS
gasoline
1-cylinder 2-valve
air-cooled horizontal-shaft
Displacement	512 cc 31.27 ci
Bore/Stroke	3.50x3.25 inches 89 x 83 mm
Power (gross)	14 hp 10.4 kW
Starter volts	12

Transmission
Transmission	Sundstrand 15
Type	shaft-driven hydrostatic
Gears	infinite forward and reverse
Oil capacity	5 qts 4.7 L
Oil change	500 h

Dimensions
Wheelbase	46 inches 116 cm
Length	69 inches 175 cm
Width	42.5 inches 107 cm
Height	44 inches 111 cm
Weight	760 lbs 344 kg
