John Deere 1600 Turbo Series II
Type: Front-mount Mowers
Contents:
Production | |
| Manufacturer | John Deere |
| Type | Front-mount mower |
| Factory | Fuquay-Varina, North Carolina, USA |
Mechanical | |
| Chassis | 4x4 MRWD 4WD |
| Final drives | planetary |
| Differential lock | mechanical front |
| Steering | power |
| Brakes | wet disc |
| Cab | Two-post ROPS. |
Power Take-off (PTO) | |
| Front PTO | independent |
Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
Engine Detail | |
| Yanmar 4TNV84T | |
| turbocharged diesel | |
| 4-cylinder | |
| liquid-cooled horizontal-shaft inline | |
| Displacement | 1994 cc 121.7 ci |
| Bore/Stroke | 3.31x3.54 inches 84 x 90 mm |
| Power (gross) | 57.3 hp 42.7 kW |
| Fuel system | direct injection |
| Air cleaner | dry |
| Compression | 19:1 |
| Rated RPM | 3000 |
| Torque | 117.3 lb-ft 159.1 Nm |
| Starter | electric |
| Starter volts | 12 |
Transmission | |
| Transmission | Kanzaki |
| Type | hydrostatic |
| Gears | infinite forward and reverse (2-range) |
Dimensions | |
| Wheelbase | 60 inches 152 cm |
| Length | 132 inches 335 cm |
| Width | 84 inches (transport) 213 cm |
| 134 inches (mowing) 340 cm | |
| Height (ROPS) | 77 inches 195 cm |
| Weight | 3950 lbs 1791 kg |
| Ground clearance | 6.5 inches 16 cm |
