John Deere 112
Type: Garden Tractors
Contents:
Production | |
| Manufacturer | John Deere |
| Type | Garden tractor |
| Factory | Horicon, Wisconsin, USA |
Variants | |
| 112H | hydraulic lift |
Mechanical | |
| Chassis | 4x2 2WD |
| Steering | manual |
| Cab | Open operator station. |
Capacity | |
| Fuel | 1.9 gal 7.2 L |
| Hydraulic system | 1.25 gal 4.7 L |
Hydraulics | |
| Capacity | 1.25 gal 4.7 L |
112 Serial Numbers | |
| 1966 | 2551 |
| 1967 | 3551 |
| 1968 | 100001 |
| 1969 | 130001 |
| 1970 | 160000 |
| 1971 | 185001 |
| 1972 | 250001 |
| 1973 | 260001 |
| 1974 | 300001 |
112 Serial Location | |
| Serial number plate located below steering column. |
Electrical | |
| Ground | negative |
| Battery volts | 12 |
Engine Detail | |
| Tecumseh HH100 | |
| gasoline | |
| 1-cylinder | |
| air-cooled horizontal-shaft | |
| Displacement | 388 cc 23.7 ci |
| Bore/Stroke | 3.3125x2.75 inches 84 x 70 mm |
| Power | 10 hp 7.5 kW |
| Rated RPM | 3600 |
| Idle RPM | 1200-3800 |
| Starter volts | 12 |
Transmission | |
| Transmission | Peerless 2300 |
| Type | gear with variable pulley drive |
| Gears | 4 forward and 1 reverse |
| Oil capacity | 1.5 qts 1.4 L |
| Oil change | 200 h |
| Four-speed gear shift with reverse using the combination brake-clutch foot pedal. Right-hand Variator lever allows on-the-move adjustment within a range of speeds for each gear. | |
Dimensions | |
| Wheelbase | 44 inches 111 cm |
| Length | 63 inches 160 cm |
| Width | 37 inches 93 cm |
| Height | 38.75 inches 98 cm |
| Weight | 591 lbs 268 kg |
| Front tread | 30 inches 76 cm |
| Rear tread | 27/33 inches 68/83 cm |
