Jacobsen 80 53132

Production: 1977 - 1980

Production
Manufacturer	Jacobsen
Type	Lawn tractor
Original price	$1,469 (1979 )

Mechanical
Chassis	4x2 2WD
Steering	manual
Brakes	mechanical disc
Cab	Open operator station.

Power Take-off (PTO)
Mid PTO	independent
Clutch	manual

Electrical
Ground	negative
Charging amps	3 (battery)
5 (lights)
Battery volts	12
Battery AH	22

Engine Detail
Briggs & Stratton 190000
gasoline
1-cylinder
air-cooled vertical shaft
Displacement	318 cc 19.44 ci
Bore/Stroke	3.00x2.75 inches 76 x 70 mm
Power	8 hp 6.0 kW
Starter	electric
Starter volts	12

Transmission
Type	belt-driven gear
Gears	3 forward and 1 reverse
Clutch	idler pulley

Dimensions
Wheelbase	42 inches 106 cm
Length	58 inches 147 cm
Width	32 inches 81 cm
Height (steering wheel)	37 inches 93 cm
Weight	408 lbs 185 kg
Ground clearance	5.25 inches 13 cm
