Ingersoll 6020
Contents:
Production | |
| Manufacturer | Ingersoll |
| Factory | Winneconne, Wisconsin, USA |
Variants | |
| 6020 | 2WD |
| 7020 | 4WD |
Mechanical | |
| Chassis | 4x2 2WD |
| Steering | hydraulic power |
Capacity | |
| Fuel | 6.4 gal 24.2 L |
| Hydraulic system | 5 gal 18.9 L |
Hydraulics | |
| Capacity | 5 gal 18.9 L |
Electrical | |
| Charging system | 15 |
| Charging amps | alternator |
| Battery CCA | 300 |
| Battery volts | 12 |
Engine Detail | |
| Kohler CH20 | |
| gasoline | |
| 2-cylinder | |
| air-cooled | |
| Displacement | 640 cc 39.1 ci |
| Bore/Stroke | 3.03x2.64 inches 77 x 67 mm |
| Power | 20 hp 14.9 kW |
| Rated RPM | 3600 |
| Oil capacity | 2 qts 1.9 L |
Transmission | |
| Transmission | Hy-drive |
| Gears | infinite forward and reverse (2-range) |
Dimensions | |
| Shiping weight | 1,380 lbs (with loader) 625 kg |
| 3,040 lbs (with loader/backhoe) 1378 kg | |
