Homelite T-8

Production: 1972 - 1976

Production
Distributor	Homelite (a part of Textron)
Manufacturer	Allis-Chalmers
Type	Garden tractor
Original price	$760 (1973 )
Original price	$999 (1975 )

Mechanical
Chassis	4x2 2WD
Steering	manual
Brakes	mechnical band
Cab	Open operator station.

Electrical
Ground	negative
Charging amps	3
Battery volts	12

Engine Detail
Briggs & Stratton 191707
gasoline
1-cylinder
air-cooled vertical-shaft
Displacement	318 cc 19.44 ci
Bore/Stroke	3.00x2.75 inches 76 x 70 mm
Power (gross)	8 hp 6.0 kW
Air cleaner	oiled foam
Starter	electric
Starter volts	12

Transmission
Type	belt-driven gear
Gears	3 forward and 1 reverse
Oil type	SAE 90

Dimensions
Wheelbase	39.75 inches 100 cm
Length	56 inches 142 cm
Width	31.5 inches 80 cm
Height (steering wheel)	34 inches 86 cm
Height (hood)	31 inches 78 cm
Weight	480 lbs 217 kg
Clearance (front axle)	9.5 inches 24 cm
Clearance (rear axle)	3.75 inches 9 cm
Front tread	25.5 inches 64 cm
Rear tread	22.5 inches 57 cm
