Hesston H-140 GMT
Type: Garden Tractors
Contents:
Production | |
| Manufacturer: | Hesston |
| Type: | Garden tractor |
| Factory: | Indianapolis, Indiana, USA |
| Original price: | $1,785 (1972 ) |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | manual articulated |
| Brakes: | mechanical disc |
| Transmission: | hydrostatic |
Capacity | |
| Fuel: | 1.5 gal 5.7 L |
Tractor hitch | |
| Type: | sleeve hitch |
| Rear lift: | 300 lbs 136 kg *At 711mm behind the rear axle. |
Power Take-off (PTO) | |
| Front PTO: | independent |
| Clutch: | electromagnetic |
Electrical | |
| Charging system: | generator |
| Charging amps: | 15 |
Engine Detail | |
| Briggs & Stratton 325431 | |
| gasoline | |
| 1-cylinder | |
| air-cooled horizontal-shaft | |
| Displacement: | 531 cc 32.4 ci |
| Bore/Stroke: | 3.56x3.25 inches 90 x 83 mm |
| Power: | 14 hp 10.4 kW |
| Starter: | electric |
| Starter volts: | 12 |
| Oil capacity: | 2 qts 1.9 L |
Transmission | |
| Transmission: | Sundstrand |
| Type: | hydrostatic |
| Gears: | infinite forward and reverse |
| Oil capacity: | 5 qts 4.7 L |
Dimensions | |
| Wheelbase: | 38.5 inches 97 cm |
| Length: | 84.25 inches 213 cm |
| Width: | 40 inches 101 cm |
| Height: | 45 inches 114 cm |
| Weight: | 800 lbs 362 kg |
| Front tread: | 31.5 inches 80 cm |
| Rear tread: | 31.5 inches 80 cm |
